2D Light Plot – User Manual
Close
1) Quick Start
Set
Stage Dimensions
(width/depth) and click
Apply
.
Drag a
Truss
or a
Fixture
from the palette onto the plan.
Click
an item to select it.
2) Moving Items
Drag items to reposition them.
If
Snap
is ON, positions snap to the grid.
3) Trusses
Drag the blue end handles to change the
length
(rotation stays fixed).
Rotate with
R
/
Shift+R
(+/- 15°) or fine-rotate with
F
/
Shift+F
(+/- 1°).
4) Fixtures & Truss Attach
With
Snap
ON, fixtures close to a truss will
attach
automatically.
Attached fixtures move with the truss.
Use
Detach
to break the link.
5) Labels
Select an item and press
L
(or click
Label
).
Labels are shown above items.
6) Duplicate
Press
D
(or click
Duplicate
) to duplicate the selected item.
The copy is placed slightly offset (down/right).
7) Units & Rulers
Switch between
Metric (m)
and
US (ft)
in the Units selector.
Rulers show distances from the
0 point
(stage center) with negative/positive values.
8) Screenshot Export
Use
Screenshot (PNG)
to export the current view.
Keyboard Summary
R
/
Shift+R
: rotate +/-15°
F
/
Shift+F
: rotate +/-1°
L
: edit label
D
: duplicate
Del
: delete
